Professional 110 IDC / Krone IDC Cat3 Patch Panel , 25 / 50 Port Voice Patch Panel 6P4C

Product Categories

Cixi Anshi Communication Equipment Co.,Ltd

Trust Seal

Verified Supplier

Credit Check

Supplier Assessment

Contact Now

Name: Professional 110 IDC Krone IDC Cat3 Patch Panel 25 50 Port Voice Patch Panel 6P4C
Brand: ANSHI
Price: 1 USD

Brand Name : ANSHI

Model Number : AS-PL-V25/50

Certification : SGS, DAS, ISO9001

Place of Origin : ZHEJIANG, CHINA

MOQ : 300 pcs, Can negotiation

Price : Negotiable

Supply Ability : 5000 Pieces Per Week

Packaging Details : 1pc/Box, 25 Boxes/Carton

Material : cold roll steel

Color : Black

Category : RJ45-RJ21

Type : 110 IDC/ Krone IDC

Port : 25 or 50 port

Contact Now

25/50 Port Voice Patch Panel (6P4C) 110-IDC/Krone-IDC use with Voice CAT 3 modules

All Panels Comply with the EIA/TIA standard for Category 3 and are avaliable in 25 port density.

Features & Benefits:

Space saving high density 1U
Meets or exceeds the requirements proposed by TIA/EIA 568 B 2, ISO/IEC 11801 Category 3
Black electrostatic powder-coated corrosion-resistant steel
25 port Voice Patch Panel
Sturdy aluminium plate around Jacks
Termination accepts 22, 23, 24 and 26 AWG (0.64-0.4) solid wires
Easy wiring installation, fit for 110 punch-down tools
Phosphor Bronze, 6-50 micro inches gold plated

Mechanical Characteristics:

Insertion Life	750 cycles minimum
IDC Life	200 times (22-26 AWG solid wire) minimum
Plug/Jack Contact Force	100g minimum using FCC-approved plug
Insulation Resistance	100Mohms minmum
Contact Resistance	7Mohms Maximum
Dielectricity Intensity	AC 1000Vrms, 50Hz or 60Hz in 60s
Plating	Sliver/Gold
Plating Thickness	1.25um, 5um/3u'', 6u'', 15u'', 30u'', 50u''

Professional 110 IDC / Krone IDC Cat3 Patch Panel , 25 / 50 Port Voice Patch Panel 6P4C

Professional 110 IDC / Krone IDC Cat3 Patch Panel , 25 / 50 Port Voice Patch Panel 6P4C
